NETUM NT-EM61 Embedded 1D/2D Barcode Scanner Module � Multi-Interface (USB/TTL / RS232 / RS485) Industrial-Grade Compact Fixed Barcode Reader
The NETUM NT-EM61 Embedded Scanning Engine is a high-performance barcode
scanner module specifically designed for embedded systems such as kiosks,
vending machines, smart lockers, and industrial control equipment. It supports
a wide range of 1D and 2D barcode formats (including EAN, UPC, Code128, QR
Code, DataMatrix, and PDF417). With multiple interface options�USB HID/USB
COM, TTL, and customizable RS232/RS485�the NT-EM61 offers excellent
compatibility and flexibility for different integration scenarios. Built with
industrial-grade standards, it operates reliably under -20�C to +60�C, and
passes rigorous tests for vibration, impact, and thermal shock.Its compact
form factor (77.8 � 66.4 � 44.7 mm) and light weight (about 70 g) make it
ideal for space-constrained devices. The scanner delivers fast and accurate
barcode recognition, even for motion or low-contrast codes, ensuring smooth
performance in demanding environments.With wide voltage input (5V�16V
customizable) and stable performance, the NT-EM61 is perfectly suited for
retail, finance, logistics, and industrial automation
applications.Specification1.Scanning Performance Image Sensor: 640 x 480 CMOS
Lighting: White LED, 6500K Supported Symbolizes: 2D: PDF417, Data Matrix, QR
Code, HanXin, AZTEC, MaxiCode 1D: EAN-13, EAN-8, UPC-A, UPC-E, Code 39, Code
128, ISBN, Code 93, Code 11, UCC/EAN-128, GS1 Databar, Interleaved 2 of 5,
Matrix 2 of 5, Industrial 2 of 5, Codabar, Standard 2 of 5, MSI-Plessey, GS1
Composite Code, etc. Reading Accuracy: 1D ? 5 mil, 2D ? 7 mil Typical Depth of
Field: 10�130 cm (Alipay QR Code) 20�100 cm (EAN13, 13 mil) Symbol Contrast
Sensitivity: ? 20% Barcode Sensitivity: Pitch �55�, Skew �55�, Roll 360� Angle
of View: Horizontal 66�, Vertical 50� 1.Mechanical / Electrical Parameters
Communication Interface: USB, USB HID, USB COM, TTL COM (Customizable: RS232,
RS485) Dimensions (mm): 77.8 (D) � 66.4 (W) � 44.7 (H) Weight: 70 g Operating
Voltage: Power Supply 1: 5�16V (Customizable) Power Supply 2: 4�6V (Default)
Note: Only one power source may be used at a time. Rated Current (Typical):
<190 mA @ 5V input 2.Environmental Parameters Operating Temperature: -20�C ~
+60�C Storage Temperature: -40�C ~ +70�C WorkingHumidity: 5% ~ 95% (Non-
condensing) Ambient Light: 0 ~ 100,000 Lux 3.Thermal Shock Resistance Maximum
Temperature: +60�C (140�F) Minimum Temperature: -20�C (-4�F) Cycle Mode: 30
min high temperature / 30 min low temperature Total Cycles: 24 4.Mechanical
Shock Resistance Vibration: 2000 G, 0.7 ms, half-sine, 3 axes Drop Test: 1.2 m
drop onto concrete floor 5.RJ45 Interface Wiring Diagram Pin No.1, Signal: NC,
Type:-, Description: Not connected Pin No.2, Signal: VCC, Type:Power,
Description: 4�6V (Default) / 5�16V (Customizable) Pin No.3, Signal: D�,
Type:I/?, Description: USB D�Signal Pin No.4, Signal: D+, Type:I/?,
Description: USB D+ Signal Pin No.5, Signal: GND, Type:-, Description: Ground
Pin No.6, Signal: I?-Y, Type:I, Description: Customizable RS232-TX or RS485-B
Pin No.7, Signal: I?-X, Type:?, Description: Customizable RS232-RX or RS485-A
Pin No.8, Signal: NC / RESET, Type:-, Description: Default NC; Customizable
Reset Input (Low level active, ?100 ?s low pulse resets device) Pin No.9,
Signal: nTrig, Type:I, Description: Trigger Input, Low level active Pin No.10,
Signal: NC, Type:-, Description: Not connected 6.Standard Type-C USB Interface
Power is supplied through a Type-C USB cable. Ensure the power voltage remains
within 4.5V�6.5V. Do not exceed this range to avoid damage.

Product Features



High-Performance Hybrid Scanning: Supports both 1D and 2D barcode types including EAN-13, QR Code, PDF417, and DataMatrix for versatile scanning applications.

Excellent Motion Tolerance & Scanning Sensitivity: Captures barcodes quickly and accurately, even when the target or device is moving. The NT-EM61 ensures reliable reading of barcodes, maintaining high decoding speed and precision in dynamic or high-throughput environments such as production lines, logistics stations, and retail checkouts.

Multiple Communication Interfaces: Offers USB, TTL, and customizable RS232 / RS485 connections for flexible system integration.

Industrial-Grade Durability: Designed to withstand temperature extremes, shock, and vibration; ideal for harsh industrial environments.

Compact and Lightweight Design: Measures only 77.8  66.4  44.7 mm and weighs about 70 g, saving installation space while ensuring easy integration.
