Force Sensing Resistor Force Sensor RP-S40-ST RP-C7.6-ST Pressure Sensor Thin Film Sensing Resistor for Intelligent High End Seat
Features:The flexible sensor has the characteristics of flexible ultra-low
power consumption and extreme speed response, etc. Small size, this flexible
pressure sensor is based on new nanometer pressure-sensitive materials
supplemented by film substrate. This pressure sensor has the characteristic of
high stability, high consistency. Highly sensitive flexible nanometer
materials can realize highly sensitive detection of pressure. When sensor
detects outside pressure, the of sensor will change. Pressure can be converted
into a corresponding electrical output using simple circuit. Specifications:
Model: RP-S40-ST Manufacturing process: thin film Output : analog Pressure
induction range: 20g-10kg : 20 g, default <200kΩ, Thickness: 0.45mm Not
resistance: > 10MΩ Activation time: <0.01s Delay: +10%, (RF+-RF-)/FR+,1000g
force Response time: <10ms Size: 5 x 4cm / 1.97 x 1.57in Weight: 3g Package
included: 1 x Pressure Sensor

Product Features



Small size, this flexible pressure sensor is based on new nanometer pressure-sensitive materials supplemented by film substrate.

This pressure sensor has the characteristic of high stability, high consistency.

The flexible sensor has the characteristics of flexible ultra-low power consumption and extreme speed response, etc.

Highly sensitive flexible nanometer materials can realize highly sensitive detection of pressure.

When thin film pressure sensor detects outside pressure, the of sensor will change.
