BSIDE Open Jaw Digital Multimeter DC AC Current Clamp Meter, Rechargeable with Smart Mode, Measures Capacitance Diode Duty Cycle Amp Resistance Hz Continuity V-Alert Live Check Environment Temperature
Features: Color display clamp meter TRMS digital smart multimeter Open jaw
design with rechargeable battery Professional dc ac current clamp ammeter Also
can be used as a professional voltage tester Measure capacitance, diode, duty
cycle and environment temperature Measure voltage, resistance, frequency,
continuity, v-alert and live wire check Auto range, Auto power off, low
battery indication with flashlight Specifications: Display: 6000 counts DC
current: 1-100A 0.1A ±(2.5%+5) AC current: 1-100A (40-100 Hz) 0.1A ±(2.5%+5)
DC voltage: 0.001-5.999V 0.001 V ±(0.8%+3); 6-59.99V 0.01 V ±(0.8%+3);
60-599.9V 0.1 V ±(1%+5); 600-610V 1 V ±(1%+5) AC voltage: 0.05-5.999V 0.001 V
±(1%+3); 6-59.99V 0.01 V ±(1%+3); 60-599.9V 0.1 V ±(1.2%+5); 600-610V 1 V
±(1.2%+5) Resistance: 0.1-599.9Ω 0.1Ω ±(1.2%+3); 0.6K-5.999KΩ 0.001KΩ
±(1.2%+3); 6K-59.99KΩ 0.01KΩ ±(1.2%+3); 60K-599.9KΩ 0.1KΩ ±(1.2%+3);
0.6M-5.999MΩ 0.001MΩ ±(2%+10); 6M-60MΩ 0.01MΩ ±(2%+10); Capacitance:
0.01µF-5.999µF 0.001µF ±(3.5%+8); 6µF-59.99µF 0.01µF ±(3.5%+8); 60µF-599.9µF
0.1µF ±(3.5%+8); 0.6mF-5.999MF 0.001mF ±(4.5%+10); 6mF-60mF 0.01mF ±(4.5%+10)
Frequency: 1-9.999Hz 0.001Hz ±(2.0%+10); 10-99.99Hz 0.01Hz ±(2.0%+10);
100-999.9Hz 0.1Hz ±(2.0%+10); 1K-9.9KHz 0.001KHz ±(2.5%+12); 10K-99.9KHz
0.01KHz ±(2.5%+12); 100K-999.9KHz 0.1KHz ±(2.5%+12); 1M-9.999MHz 0.001MHz
±(3%+15); Duty Cycle: 10%-95% 0.1 ±3% Diode: Measure diodes within 3.0V
Continuity: The beeper sounds when resistance less 50Ω Temperature: 0-50℃ ±2℃
V-Alert: Yes Live wire check: Yes Power: rechargeable 3.7 V battery (built-in)
Size: 192 x 36 x 30 mm Weight: 102 g Package Includes: 1 x Digital Clamp Meter
1 x Test Leads 1 x Charging Cable 1 x Carrying Case 1 x Battery 1 x User
Manual

Product Features



[Open Jaw Design]: True RMS multimeter with open jaw design for easily measurement in tight space, such as inverter, hub or intensive line.

[Smart Mode]: This smart digital multimeter can automatically measure ac and dc voltage, resistance and continuity with the best resolution. All of this functions measurement can be done manually as well.

[3-IN-1 Design]: The pocket multimeter can not only be used as a dc ac amp clamp meter, but also can be used as a professional voltage tester.

[Amp Automatically Identification]: The digital clamp multimeter can automatically measures dc and ac current with jaw, the measurement can be done manually as well. It support to zero out the readings influenced by earth's magnetic.

[Rechargeable]: The digital voltmeter comes with a rechargeable battery & charging cable, ensuring that you never have to worry about running out of power during your measurements.
